Ibicuruzwa bisobanura
AIRTAC 4V400 ikurikirana ya solenoid valves itanga ubushobozi bunini bwo gutembera hamwe numubiri ukomeye kandi uramba, bigatuma bahitamo guhitamo sisitemu ziremereye -. Zitanga ikirere cyizewe kuri silinderi nini nibikoresho byo hejuru -, bikoresha neza imikorere yumurongo wimashini zikoresha imashini. Nkumushinwa wizewe utanga pneumatike, dutanga indege nyayo ya AIRTAC 4V400 hamwe nibiciro byapiganwa nibihe byihuse byo kuyobora imishinga yawe.
|
Uburyo bwo gutumiza 4V400 Urukurikirane Pneumatic Solenoid Valve |
||||||
|
4 V 4 10 15 A ¨ ¨ |
||||||
|
① ② ③ ④ ⑤ ⑥ ⑦ |
||||||
|
OdModel |
Ode Kode |
Type Ubwoko bw'agaciro |
Size Ingano nini |
OlUmuriro |
Ent Kwinjira mu mashanyarazi |
Type Ubwoko bw'amasomo |
|
4V: Solenoid indanga (5 / 2,5 / 3 inzira) |
4: 400 Urukurikirane |
10: Inzira imwe ya solenoid 5/2 inzira |
15:1/2" |
Igisubizo: AC220V B: DC24V C: AC110V E: AC24V F: DC12V |
Ubusa: Terminal I: Grommet |
Ubusa: PT G:G T: NPT |
|
20: Kabiri solenoid 5/2 inzira |
||||||
|
30C: Double solenoid 5/3 inzira ifunze hagati |
||||||
|
30E: Kabiri solenoid 5/3 inzira Umuyoboro |
||||||
|
30P: Double solenoid 5/3 inzira yumuvuduko |
||||||
Shikira nonaha kugirango ubone ibisobanuro bya valve, kataloge ya tekiniki, hamwe nigiciro cyiza cya AIRTAC 4V400 seri ya solenoid valve, ushyigikire ibikenewe - bikenewe.
4V400UrukurikiranePneumatic Solenoid ValveIbipimo bya tekiniki
|
4V400UrukurikiranePneumatic Solenoid Valve Ibyingenzi Ibisobanuro |
|||||
|
Icyitegererezo |
4V410-15 |
4V420-15 |
4V430C-15 |
4V430E-15 |
4V430P-15 |
|
Amazi |
Umwuka (kugirango ushungurwe na 40μm filteri yibintu) |
||||
|
Gukina |
Umudereva w'imbere cyangwa umuderevu wo hanze |
||||
|
Ingano yicyambu [Icyitonderwa1] |
n=Hanze=Umunaniro =1 / 2 " |
||||
|
Ingano ya Orifice |
50.0mm² (Cv =2.79) |
30.0mm² (Cv =1.68) |
|||
|
Ubwoko bwa Valve |
5 icyambu 2 umwanya |
5 icyambu 3 umwanya |
|||
|
Umuvuduko wo gukora |
0.15 ~ 0.8MPa (21 ~ 114psi) |
||||
|
Kwemeza |
1.2MPa (175psi) |
||||
|
Ubushyuhe |
-20 ~ 70 dogere |
||||
|
Ibikoresho byumubiri |
Aluminiyumu |
||||
|
Amavuta [Icyitonderwa2] |
Ntabwo bisabwa |
||||
|
Ikirangantego [Icyitonderwa3] |
3cycle / amasegonda |
||||
|
Ibiro (g) |
590 |
720 |
770 |
||
|
[Icyitonderwa1] Urudodo rwa PT, Urudodo G na NPT irahari. |
|||||
|
Icyitonderwa2] Umwuka umaze gukoreshwa, komeza hamwe nuburyo bumwe kugirango ubeho neza. |
|||||
|
[Icyitonderwa3] Umubare ntarengwa wibikorwa ni muri no - umutwaro. |
|||||
