Ibicuruzwa bisobanura
AIRTAC 4V300 ikurikirana ya solenoid valve yakozwe hamwe numubiri munini hamwe nubushobozi bwo gutembera cyane ugereranije nurutonde rwa 4V200, bigatuma bikenerwa no gusaba sisitemu yo gukoresha pneumatike isaba umuyaga mwinshi no gutanga. Ubwubatsi bwabo bukomeye butanga imikorere yizewe mugukora uruganda, imirongo yo gupakira, hamwe nibikoresho bya mashini. Dutanga AIRTAC 4V300 yumwimerere kubiciro byamasoko yubushinwa hamwe no gutanga byihuse kwisi yose.
|
Uburyo bwo gutumiza 4V300 Urukurikirane Pneumatic Solenoid Valve |
||||||
|
4V 3 10 10 A ¨ ¨ |
||||||
|
① ② ③ ④ ⑤ ⑥ ⑦ |
||||||
|
OdModel |
Ode Kode |
Type Ubwoko bw'agaciro |
Size Ingano nini |
OlUmuriro |
Ent Kwinjira mu mashanyarazi |
Type Ubwoko bw'amasomo |
|
4V: Solenoid indanga (5 / 2,5 / 3 inzira) |
3: 300 Urukurikirane |
10: Inzira imwe ya solenoid 5/2 inzira |
08:1/4" 10:3/8" |
Igisubizo: AC220V B: DC24V C: AC110V E: AC24V F: DC12V |
Ubusa: Terminal I: Grommet |
Ubusa: PT G:G T: NPT |
|
20: Kabiri solenoid 5/2 inzira |
||||||
|
30C: Double solenoid 5/3 inzira ifunze hagati |
||||||
|
30E: Kabiri solenoid 5/3 inzira Umuyoboro |
||||||
|
30P: Double solenoid 5/3 inzira yumuvuduko |
||||||
Menyesha itsinda ryacu uyumunsi ibisobanuro birambuye byibicuruzwa, urupapuro rwerekana ibipimo, hamwe namagambo yatanzwe kurushanwa kuri AIRTAC 4V300 seriveri ya solenoid valves kubikorwa byawe byinganda.
4V300UrukurikiranePneumatic Solenoid ValveIbipimo bya tekiniki
|
4V300UrukurikiranePneumatic Solenoid Valve Ibyingenzi Ibisobanuro |
||||
|
Icyitegererezo |
4V310-08 |
4V330C-08 |
4V310-10 |
4V330C-10 |
|
Amazi |
Umwuka (kugirango ushungurwe na 40μm filteri yibintu) |
|||
|
Gukina |
Umudereva w'imbere cyangwa umuderevu wo hanze |
|||
|
Ingano yicyambu [Icyitonderwa1] |
n=Hanze=Umunaniro =1 / 4 " |
Muri=Hanze =3 / 8 "Umunaniro =1 / 4" |
||
|
Ingano ya Orifice |
25.0mm² |
18.0mm² |
30.0mm² |
18.0mm² |
|
Ubwoko bwa Valve |
Umwanya wa port2 |
5 icyambu 3 umwanya |
5 icyambu 2 umwanya |
5 icyambu 3 umwanya |
|
Umuvuduko wo gukora |
0.15 ~ 0.8MPa (21 ~ 114psi) |
|||
|
Umuvuduko |
1.2MPa (175psi) |
|||
|
Ubushyuhe |
-20 ~ 70 dogere |
|||
|
Ibikoresho byumubiri |
Aluminiyumu |
|||
|
Amavuta [Icyitonderwa2] |
Ntabwo bisabwa |
|||
|
Ikirangantego [Icyitonderwa3] |
4 cycle / amasegonda |
3 cycle / amasegonda |
4 cycle / amasegonda |
3 cycle / amasegonda |
|
Ibiro (g) |
4V310-08:310 |
450 |
4V310-10:310 |
450 |
|
[Icyitonderwa1] Urudodo rwa PT, Urudodo G na NPT irahari. |
||||
|
[Icyitonderwa2] Umwuka umaze gukoreshwa, komeza hamwe nuburyo bumwe kugirango uhindure ubuzima bwa valve |
||||
